FMWR-N Manual Wheelchair Ramp For Bus

manual wheelchair ramp bus
manual wheelchair ramp bus 2
manual wheelchair ramp bus 3
manual wheelchair ramp bus 4
manual wheelchair ramp bus
manual wheelchair ramp bus 2
manual wheelchair ramp bus 3
manual wheelchair ramp bus 4

  • FMWR-N Manual Wheelchair Ramp can be applied for low-floor city bus.
  • It can help wheelchair occupant to enter bus comfortably and easily while seated in a wheelchair.
  • It is installed on floor and flat with floor when not use.

  • It doesn’t obstruct view, access and emergency exit.
  • This ramp is operated manually by pulling the handle.
  • Main material is aluminum which is light and with high corrosion resistance.
  • There is sensor inside of ramp, so that the driver can know whether the ramp is under performance status.

Advantages:

  • Interlock system: sensor inside to indicate ramp status;
  • Anti-skip platform; Platform option:aluminium checkered plate or black anti-slip cover;
  • Flat with floor when not in use;
  • Doesn’t obstruct view, access and emergency exit.
  • Max Loading Capacity: 350 Kg;
  • light, thick and with high corrosion resistance;
  • handle for easy operation;

Tests:

  • 350KG static loading strength test;
  • Dynamic pedaling simulation test;
  • Dynamic drop operation simulation test;
  • 2001/95/EC certified;

Technical:

  • Max Loading Capacity: 350 Kg;
  • Platform option: aluminum checkered plate or black anti-slip covering;
  • Own weight: 27.5 kg;
